| Length | 7850 mm. |
| Width | 1900 mm. |
| Height over protective roof | 2213 mm. |
| Wheelbase | 3860 mm. |
| Track | 2240 mm. |
| Ground clearance | 360 mm. |
| Turning radius (outer min.) | 7850 mm. |
| Turning radius (inner) | 4330 mm. |
| Operating weight | 9,000 kg. |
ENGINE
| Cummins QSB3.9 | 98 kW |
| In-line 4-cylinder turbodiesel | 133.2l/s |
| liquid cooling. | at |
| The engine is approved for mines. | 2300 rpm |
TRACTION AND SPEED CHARACTERISTICS
| 1st gear | 6 km/h |
| 2nd gear | 12 km/h |
| 3rd gear | 22 km/h |
| Maximum traction | 133 kN |
TRANSMISSION
| Dana 24,000 Series Hydromechanical Transmission with Hydraulic Pump Drive |
| 3 speeds forward and reverse |
| Four-wheel drive |
AXLE
| DANA112 with planetary wheel gears | |
| The rear axle is fixed | |
| Front axle swinging | +/- 10° |
| Front axle hydraulic suspension | |
BRAKES
| Service brake: hydraulic dual-circuit closed-design brake system, multi-disc brakes in an oil bath on both axles. |
| Safety/Parking Brake: Reverse acting, normally spring loaded, hydraulically released |
TIRES pneumatic, 12.00 - 20 PR 20
STEERING Hydraulic articulated steering, Orbitrol type
ELECTRICAL SYSTEM
| External parts have a protection level of at least IP 54 | |
| Mains voltage | ±24 V |
| Battery | 2 × 115 Ah |
| Generator | 100 A |
| LED running lights | 6 pcs. |
| LED work lights | 2 pcs. |
| LED Work lights in basket | 2 pcs. |
| LED work lights on protective roof/guard | 2 pcs. |
| LED Reversing lights | 2 pcs. |
| Yellow flashing beacon | 1 pc. |
| Blue flashing light | 1 pc. |
| Sound and light signaling of reverse gear | |
| Yellow LED side lights | |
| LED parking lights, brake lights, turn signals and indicator lights | |
| Self-extinguishing wiring harnesses in a fireproof and waterproof casing | |
| *Rear view camera | |
| *Video recording system with 4 video cameras | |
